INSTALL

CORNERS

Mitre cut the Smart Screen® panels using the inside and outside corner mitre templates supplied on the inside panel of each box.

CLICK HERE TO DOWNLOAD MITRE INSTRUCTIONS

HOW TO INSTALL
SMART SCREEN®

STEP 1

Align Smart Screen® panel with the front edge of the gutter and fasten Smart Screen® panel at the front with a supplied panhead screw into the recessed hole.

STEP 2

Fasten rear of Smart Screen® panel to the fascia using a supplied panhead screw.

The Smart Screen® panel (the middle portion with the hole pattern) should be level from the front of your gutters / eavestrough to the back. (But follow the slope of your gutters along the side of your house.)

STEP 3

Overlap Smart Screen® panels using the cut-out guides at the end of each panel.

CLICK HERE TO DOWNLOAD SMARTSCREEN® INSTRUCTIONS
